Series no. | 4-10 series | Feature selection |
---|---|---|
Performance | Impeller diameter | 800-2950mm |
Rotation speed | 580-1450r/min | |
Pressure range | 553-7218Pa | |
Flow range | 15229-810000m³/h | |
Structure | Blade type | Backward, Straight, Aerofoil type |
Impeller support | SWSI(Single Width, Single Inlet), DWDI(Double Width, Double Inlet), Overhung type | |
Lubrication method | Oil bath lubrication, grease lubrication, lubrication oil station | |
Cooling method | Air cooling, Water cooling, Oil cooling | |
Driven mode | Direct driven, Coupling driven, Belt driven | |
Gas composition | Gas temperature | Normal | Customer request |
gas characteristic | Clean gas | Corrosive gas | |
System configuration | Motor brand | Chinese famous brand, ABB, Siemens, WEG etc |
Option parts | System base frame, Protective screening, Silencer, Inlet & Outlet flexible connections, Inlet & Outlet counter flange, Air damper, Electric actuator, Shock absorber, Diaphragm coupling, Fluid coupling, Motor rain cover, Temperature sensor, Vibration sensor, Soft starter, Inverter, Special Electrical Motor, System monitoring Instrument. |
